Bar Pull
The everyday cabinet handle, fixed at both ends of the door and specified by centre-to-centre hole spacing.
Specified by hole spacing
Handles are ordered by centre-to-centre distance, not by overall length, because that is what is drilled.
Three common centres
96 mm (about 3-3/4 in), 128 mm and 160 mm cover most cabinets and drawers.
Matched to drawer width
A 450 mm drawer usually takes 128 mm centres and a 600 mm drawer 160 mm, which is the question buyers ask most.
- Types
- Straight bar pull, fixed at both ends of the door
- Common centres
- 96 mm (about 3-3/4 in), 128 mm and 160 mm
- Drawer widths
- 450 mm and 600 mm drawers usually take 128 mm and 160 mm centres
- Short lengths
- 76 mm and under, for small cabinet doors
- Adjustable centres
- Single-piece handles that cover more than one hole spacing are available where a range has to fit several cabinet sizes
- Selection basis
- Centre-to-centre hole spacing (C-C), the industry standard way of specifying a handle
- Material
- Zinc alloy (ZAMAK) or aluminium as standard; stainless steel, brass, carbon steel, ceramic and leather available
- Finish
- Matte black, brushed brass, black-gold, antique bronze, brushed nickel, gold
- Fixing
- Screw fixed, with 2 or 4 screws supplied per handle
- MOQ
- 2–1000 pcs
The bar pull is the handle most kitchens end up using: a bar fixed at both ends of the door, in a length that suits the cabinet it sits on. It is specified by centre-to-centre hole spacing rather than by overall length, because the hole spacing is what gets drilled and what determines whether the handle lines up with the drawer front.
Three spacings cover most of the work. 96 mm (about 3-3/4 in) suits wall units and small doors, 128 mm is the usual choice for a 450 mm drawer, and 160 mm for a 600 mm drawer. Short handles of 76 mm and under are used on small cabinet doors where a full bar would be out of proportion, and single-piece handles that cover more than one spacing are available where one range has to fit several cabinet sizes.
The bar is made in zinc alloy or aluminium as standard, with stainless steel, brass and carbon steel available, and finished in matte black, brushed brass, black-gold, antique bronze, brushed nickel or gold. Screws are supplied, two or four per handle depending on the fixing points.
Tell us the hole spacing, the length, the finish and the quantity, and we will quote the handle on its own or with the rest of the hardware.
